We hereto make the following quality guarantee to the NJP-400 automatic capsule filling machine purchased by the (buyer’s name: ) from us:
1. The overall product has strictly followed our company’s quality standard, as well as met the requirements of Pharmaceutical Automatic Capsule Filling Machine JB20025-2004.
2. The machine has passed the inspection of Zhejiang Packaging Machinery Product Quality Inspection Center, meeting all the requirements for passing the inspection.
3. Strictly follows the IS09001 International Quality Certification System, meeting the requirements of GMP certification.
4. The machine is produced by our company, passes the acceptance check of FAT, and completely meets the standards of user requirement specification (URS of NJP-400 automatic capsule filling machine).
| Filling capacity | 48000 pcs/hour |
| Weight | 900KG |
| Dimension | 1100*900*2050mm |
| Power supply | 380/220V 50HZ |
| Total power | 5KW |
| Segment bores | 6 holes |
| Vacuum | 40m³/h-0.04-0.08Mpa |
| Dust collector | 24.5Kpa 210m³/h |
| Air compression | Air consumption 5m³/h Pressure 5-7KG |
| Water source | 500L/h 0.1-0.2Mpa |
| Operating noise | ＜75DB(A) |
| Filling percentage | Empty capsule 99.9% filled capsule 99.8% |
| Capsule size | 00.0.1.2.3.4.5# |
| Filling accuracy | Western medicine ±3% Chinese medicine ±4% |
| Suitable for | Power, Granule,Pellet,Tablet. |
